Advantage:

● Built-in newly developed V3 version measurement system to improve the image again Clarity;

● 4K output image, real-time frame rate 60FPS;

● New: custom interface editing, custom template editing, D × f Import template, file management, measurement data export and other functions;

● SONY high-performance photosensitive chip, low noise, high sensitivity, True colors;

● Dual core 2 * A73 @ 1.6GHz 2 * A53 @ 1.2GHz;

● 4 GB DDR4 8 GB eMMO

● Equipped with USB3.0, Gigabit Ethernet interface

● High-definition pictures, videos and preview playback;

● Built-in automatic edge search function to improve the measurement effect

● Support ∪disk storage function, can be connected with an external mouse

Feature:

● Labeling functions: Point coordinates, cross lines, coordinate systems, text annotations
● Length measurement: Line length, line length, curve length, parallel line distance, point line distance
● The center distance: The radius fixed circle, two points setting circle, three points setting circle
● Geometric measurement: Line length, radius fixed circle, two point fixed circle, three point fixed circle, concentric circles
● The geometric area: Polygon, squat
● Image fast: Support for 4K static photos
● Video video: Support 4K video

Specification:

● Image sensor: FULL HD 4K industrial camera sensor/1.1.8'' inch
● Effective pixel: 8.3M
● Pixel size: 2.0um x 2.0um
● Frame rate: 4K60FPS@3840*2160
● Output interface: 4K @60FPS HDMI output,
● The storage mode built-in 4GB memory, and support the U disk(supporting FAT32 and NTFS file system)
● Power supply: DC-12V/1A
● Thread: C mount
